| 尺寸规格表 |
型号 |
规格 |
型式 |
内径(mm) |
外径(mm) |
弯曲半径
mm |
包装长度
(M/coil) |
重量
kg/M |
才积 |
最小 |
最大 |
最小 |
最大 |
YF-70503 |
3/8″ |
YF-705 |
12.3 |
12.8 |
18.5 |
19.0 |
75 |
50 |
0.47 |
1.39 |
YF-70504 |
1/2″ |
YF-705 |
15.7 |
16.3 |
21.8 |
22.3 |
95 |
50 |
0.73 |
1.73 |
YF-70506 |
3/4″ |
YF-705 |
20.7 |
21.2 |
26.2 |
27.7 |
120 |
30 |
0.77 |
1.72 |
YF-705010 |
1″ |
YF-705 |
26.2 |
26.8 |
33.8 |
34.4 |
180 |
30 |
1.38 |
2.55 |
YF-70512 |
11/4″ |
YF-705 |
34.7 |
35.4 |
42.4 |
43.2 |
230 |
20 |
2.050 |
4.21 |
YF-70514 |
11/2″ |
YF-705 |
40.0 |
40.6 |
48.4 |
49.3 |
270 |
20 |
2.640 |
5.20 |
YF-70520 |
2″ |
YF-705 |
51.3 |
51.9 |
60.4 |
61.3 |
300 |
15 |
3.390 |
5.74 |
YF-70524 |
21/2″ |
YF-705 |
62.9 |
63.6 |
73.1 |
74.0 |
350 |
10 |
3.910 |
4.22 |
YF-70530 |
3″ |
YF-705 |
77.9 |
78.7 |
88.9 |
89.9 |
500 |
10 |
4.870 |
7.60 |
YF-70540 |
4″ |
YF-705 |
101.6 |
102.6 |
114.3 |
115.3 |
650 |
5 |
7.000 |
10.92 |
|
| |
|
| |
| |
|
